GasAlertMicro 5 PID Multi Gas Detector

Item #:
XXYY-M5PID
Brand:
BW Technologies
GasAlertMicro 5 PID Multi Gas Detector
Item #
XXYY-M5PID
Oxygen
Combustible
PID Sensor
Toxic Sensor
Battery
Sampling Method
Housing
Confined Space Kits
Qty
Discontinued
Send This Page to a Friend
Send This Page to a Friend
  • JJS Technical Services
  • JJS Technical Services
  • JJS Technical Services
  • JJS Technical Services
  • JJS Technical Services
  • JJS Technical Services
  • JJS Technical Services

Ask an Expert

Our tech experts are ready to help!

1-866-4 JJSTECH (1-866-455-7832)

Email Us
Share this product:
GasAlertMicro 5 PID Multi Gas Detector

GasAlertMicro 5 PID Multi Gas Detector

Discontinued

Protect yourself

Simultaneously monitor and display up to five atmospheric hazards with the GasAlertMicro 5. Adaptable to a variety of applications, the GasAlertMicro 5 has an extensive selection of user-settable field options and is available as either a standard toxic gas model, a PID model for the detection VOCs, or an IR model for CO2 detection. Use the passcode function to prevent unauthorized modifications of the instrument’s settings. Compatible with BW’s MicroDock II automatic test and calibration system, the GasAlertMicro 5 is unparalleled in its versatility, performance and overall value.

  • Measure up to five atmospheric hazards concurrently
  • Fully customizable to suit any application
  • Rapidly switch from diffusion mode, to the optional integrated pump in the field

Standard features of BW products:

  • Continuous LCD shows real-time gas concentrations
  • Water-resistant
  • Automatic calibration procedure; compatible with BW MicroDock II automatic test and calibration station
  • Full function self-test of sensor, battery status, circuit integrity and audible/visual alarms on start up
  • Bright wide-angled visual alarm bars
  • Built-in concussion-proof boot

Additional GasAlertMicro 5 Features:

  • Integral motorized pump option for remote sampling
  • Equipped with internal vibrating alarm for high noise areas
  • Two power options: AA alkaline or rechargeable hotswappable battery packs
  • Multi-language support in English, French, German, Spanish and Portuguese

GasAlertMicro 5 Specifications:
Size 5.7 x 2.9 x 1.5 in. / 14.5 x 7.4 x 3.8 cm
Weight 13.1 oz. / 370 g
Temperature -4 to +122°F / -20 to +50°C
-14 to +104°F / -10 to +40°C (PID)
Alarms - Visual, vibrating, audible (95dB)
- Low, High, STEL, TWA, OL (over limit)
Tests Sensor integrity, circuitry, battery and audible/visual alarms on activation, battery (continuous)
Pump Optional
User options Confidence beep, Set STEL interval, Set TWA method, Sensor on/off, Latching alarms, Safe display mode, Stealth mode, Adjust Clock, Set datalogger rate, Passcode protection, Correction factor library (LEL, PID), Fast pump, Combustible gas measurement (% LEL or % by volume methane), O2 auto calibration on start up, Automatic backlight, Sleep mode, User-settable calibration gas level, Calibration due lockout, Daily bump test, Language choices (5), High resolution
Warranty Full 2 year warranty including sensors (1 year NH3 and PID lamp)


Sensor Specifications:
Gas Measuring Range (ppm) Default Resolution (ppm) High Resolution (ppm)
H2S 0-500 1.0 0.1
CO 0-999 1.0 N/A
TwinTox (H2S) 0-500 1.0 0.1
TwinTox (CO) 0-500 1.0 N/A
O2 0-30.0% 0.1% N/A
SO2 0-150 1.0 0.1
PH3 0-5.0 1.0 0.1
NH3 0-100 1.0 0.1
NO2 0-99.9 1.0 0.1
HCN 0-30.0 1.0 0.1
Cl2 0-50.0 1.0 0.1
ClO2 0-1.0 0.1 0.01
O3 0-1.0 0.1 0.01
PID (VOCs) 0-1000 1 N/A
IR (CO2) 0-50,000
0-5.0% v/v		 150
0.01%		 N/A
N/A
Combustible gases 0-100% LEL
0-5.0% v/v		 1%
0.1%		 N/A
